How to Use HAProxy on Linux Server? Setup and Configuration

To use HAProxy on a Linux server, install the package for your distro, create a front end that listens on ports 80/443, define back ends with your app servers, enable health checks and SSL termination, then start and enable the service.

This guide explains installation, configuration, security, tuning, and troubleshooting.

In this beginner-friendly guide, you’ll learn how to use HAProxy on Linux server environments to load balance traffic, terminate SSL, route by host or path, and scale web apps. We’ll cover installation on Ubuntu/Debian and RHEL-based distros, step-by-step configuration, best practices, and real-world tips from hosting production workloads.

What Is HAProxy and Why Use It?

• Primary use cases: load balancing, reverse proxy, SSL termination, Layer 4/7 routing.
• Benefits: high availability, scalability, observability, and strong performance under heavy traffic.
• Alternatives: NGINX, Envoy, Traefik—but HAProxy is renowned for speed and stability.

Prerequisites

• A Linux server (Ubuntu 22.04/24.04, Debian 12, Rocky/AlmaLinux 8/9, or RHEL 8/9).
• Root or sudo access.
• Public DNS records pointing to your HAProxy server (for HTTPS, e.g., app.example.com).
• Two or more backend application servers (or containers) to load balance.
• Basic firewall access to open ports 80 and 443 (and 8404/9000 for stats/admin if needed).

Install HAProxy on Linux

Ubuntu/Debian

sudo apt update
sudo apt install -y haproxy
haproxy -v

Rocky/AlmaLinux/RHEL

sudo dnf install -y haproxy
haproxy -v

Enable and Verify the Service

sudo systemctl enable haproxy
sudo systemctl start haproxy
sudo systemctl status haproxy

Basic HAProxy Configuration (HTTP)

HAProxy’s main config file is at /etc/haproxy/haproxy.cfg. Always validate changes before reloading. Below is a minimal yet production-ready template.

global
    log /dev/log local0
    log /dev/log local1 notice
    user haproxy
    group haproxy
    daemon
    maxconn 50000
    tune.ssl.default-dh-param 2048

defaults
    log     global
    mode    http
    option  httplog
    option  dontlognull
    timeout connect 5s
    timeout client  30s
    timeout server  30s
    retries 3
    option redispatch

frontend fe_http
    bind *:80
    mode http
    option forwardfor
    http-request set-header X-Forwarded-Proto http
    default_backend be_app

backend be_app
    mode http
    balance roundrobin
    option httpchk GET /health
    http-check expect status 200
    cookie SRV insert indirect nocache
    server app1 10.0.0.11:8080 check cookie s1
    server app2 10.0.0.12:8080 check cookie s2

• Health checks: option httpchk and http-check expect status 200 ensure only healthy servers receive traffic.
• Sticky sessions: Enable stickiness with a cookie for stateful apps (e.g., PHP sessions). For stateless apps, you can remove cookies.
• Load balancing: roundrobin is simple; consider leastconn for uneven request durations.

# Validate then reload
sudo haproxy -c -f /etc/haproxy/haproxy.cfg
sudo systemctl reload haproxy

Enable HTTPS and SSL Termination

Terminating TLS at HAProxy reduces CPU load on your app servers and centralizes certificate management. You can use Let’s Encrypt with HAProxy using a PEM bundle or a certbot hook.

Create the TLS PEM Bundle

Place your certificate and key as a single PEM file readable by HAProxy:

sudo mkdir -p /etc/haproxy/certs
sudo cat fullchain.pem privkey.pem | sudo tee /etc/haproxy/certs/app.example.com.pem >/dev/null
sudo chmod 600 /etc/haproxy/certs/app.example.com.pem
sudo chown haproxy:haproxy /etc/haproxy/certs/app.example.com.pem

HTTPS Frontend with HTTP->HTTPS Redirect

frontend fe_http
    bind *:80
    http-request redirect scheme https code 301 unless { ssl_fc }
    default_backend be_app

frontend fe_https
    bind *:443 ssl crt /etc/haproxy/certs/app.example.com.pem alpn h2,http/1.1
    mode http
    option forwardfor
    http-request set-header X-Forwarded-Proto https
    default_backend be_app

For automatic renewal, use certbot with the --deploy-hook to rebuild the PEM and reload HAProxy after renewal.

sudo certbot certonly --standalone -d app.example.com --agree-tos -m admin@example.com --non-interactive
# Deploy hook example (script should concatenate PEM and reload HAProxy)
sudo systemctl reload haproxy

Host/Path Routing with ACLs (Layer 7)

Use ACLs to route traffic by domain or URL path—ideal for microservices or splitting static/dynamic content.

frontend fe_https
    bind *:443 ssl crt /etc/haproxy/certs/app.example.com.pem
    mode http
    acl host_api hdr(host) -i api.example.com
    acl path_static path_beg /assets/ /static/
    use_backend be_api if host_api
    use_backend be_static if path_static
    default_backend be_app

backend be_api
    balance leastconn
    server api1 10.0.0.21:9000 check
    server api2 10.0.0.22:9000 check

backend be_static
    balance roundrobin
    server cdn1 10.0.0.31:8080 check

backend be_app
    balance roundrobin
    server app1 10.0.0.11:8080 check
    server app2 10.0.0.12:8080 check

Security Best Practices

• Harden TLS: Use modern ciphers and enable HTTP/2. Consider setting ssl-default-bind-ciphersuites for TLS 1.3.
• Rate limiting: Use stick tables to mitigate abusive clients.
• Least privilege: Run as the haproxy user; avoid world-readable certs.
• PROXY protocol: If terminating on a second HAProxy or a cloud LB, enable PROXY protocol to preserve client IPs.
• Firewall: Restrict management ports; only expose 80/443 publicly.

# Example: Simple rate limit by source IP (100 reqs in 10s)
frontend fe_https
    stick-table type ip size 1m expire 10s store http_req_rate(10s)
    tcp-request connection track-sc0 src
    http-request deny if { sc_http_req_rate(0) gt 100 }

Observability: Logs, Stats, and Runtime API

Proper logging and metrics are essential in production. Enable access logs and the built-in stats page or admin socket.

global
    log /dev/log local0
    stats socket /run/haproxy/admin.sock mode 660 level admin
    stats timeout 30s

listen stats
    bind *:8404
    stats enable
    stats uri /haproxy?stats
    stats refresh 10s
    stats auth admin:StrongPassword

Most distros use rsyslog. Ensure HAProxy logs are captured:

# /etc/rsyslog.d/49-haproxy.conf
$template HaproxyFormat,"%timestamp% %hostname% haproxy[%procid%]: %msg%\n"
if ($programname == "haproxy") then /var/log/haproxy.log;HaproxyFormat
& stop

sudo systemctl restart rsyslog

Performance Tuning Tips

• Max connections: Set global maxconn based on RAM and workload; increase ulimit -n if needed.
• Timeouts: Keep timeouts realistic (e.g., 30–60s for clients; 30s for servers) to prevent socket exhaustion.
• HTTP keep-alive: Enabled by default; ensures fewer TCP handshakes.
• Compression: Offload compression to app/CDN; if enabling in HAProxy, monitor CPU closely.
• Kernel tuning: Consider net.core.somaxconn, net.ipv4.ip_local_port_range, and net.ipv4.tcp_tw_reuse for high connection rates.

Common Issues and Troubleshooting

• Service won’t start: Run haproxy -c -f /etc/haproxy/haproxy.cfg to validate syntax before reloads.
• SSL errors: Ensure the PEM includes full chain + private key; permissions readable by haproxy user.
• Missing client IPs: Use option forwardfor in HTTP mode; enable PROXY protocol end-to-end if behind another LB.
• Health checks failing: Verify backend /health endpoint returns 200 quickly; check firewalls and SELinux labeling on RHEL-based systems.
• High latency: Check timeouts, server saturation, DNS issues, or Layer 7 inspection rules (ACLs) that are too heavy.

Real-World Use Cases

• Blue/Green deployments: Weight backends or switch ACLs to shift traffic gradually during releases.
• Microservices gateway: Route by host/path to different services, apply rate limits per route.
• SSL offload and WAF chain: Terminate TLS in HAProxy, then forward to a WAF or app servers.
• Multi-region failover: Use DNS health checks and multiple HAProxy nodes with VRRP/keepalived or cloud load balancers.

Deploy HAProxy on YouStable Infrastructure

For high-availability architectures, pair HAProxy with reliable compute. YouStable’s SSD-backed VPS and dedicated servers deliver low latency, generous bandwidth, and optional managed support. Spin up multiple backend instances, add a public HAProxy node, and let our team help you harden TLS, tune performance, and monitor uptime—without overspending.

Full Example: Production-Ready haproxy.cfg

global
    log /dev/log local0
    log /dev/log local1 notice
    user haproxy
    group haproxy
    daemon
    maxconn 50000
    stats socket /run/haproxy/admin.sock mode 660 level admin
    stats timeout 30s
    tune.ssl.default-dh-param 2048

defaults
    log     global
    mode    http
    option  httplog
    option  dontlognull
    timeout connect 5s
    timeout client  60s
    timeout server  60s
    retries 3

# Public HTTP (redirect to HTTPS)
frontend fe_http
    bind *:80
    http-request redirect scheme https code 301 unless { ssl_fc }
    default_backend be_app

# Public HTTPS
frontend fe_https
    bind *:443 ssl crt /etc/haproxy/certs/app.example.com.pem alpn h2,http/1.1
    option forwardfor
    http-request set-header X-Forwarded-Proto https

    # Basic rate limiting (100 req/10s/IP)
    stick-table type ip size 1m expire 10s store http_req_rate(10s)
    tcp-request connection track-sc0 src
    http-request deny if { sc_http_req_rate(0) gt 100 }

    # Host/Path routing examples
    acl host_api hdr(host) -i api.example.com
    acl path_static path_beg /assets/ /static/
    use_backend be_api if host_api
    use_backend be_static if path_static
    default_backend be_app

backend be_app
    balance roundrobin
    option httpchk GET /health
    http-check expect status 200
    cookie SRV insert indirect nocache
    server app1 10.0.0.11:8080 check cookie s1
    server app2 10.0.0.12:8080 check cookie s2

backend be_api
    balance leastconn
    option httpchk GET /health
    http-check expect status 200
    server api1 10.0.0.21:9000 check
    server api2 10.0.0.22:9000 check

backend be_static
    balance roundrobin
    server cdn1 10.0.0.31:8080 check

# Stats UI
listen stats
    bind *:8404
    stats enable
    stats uri /haproxy?stats
    stats refresh 10s
    stats auth admin:StrongPassword

How to Use HAProxy on Linux Server: Step-by-Step

• Install HAProxy via your distro package manager.
• Point DNS to your HAProxy server’s public IP.
• Create /etc/haproxy/haproxy.cfg with frontends/backends and health checks.
• Add HTTPS with a PEM certificate; redirect HTTP to HTTPS.
• Enable logs and stats; secure stats with auth and firewall rules.
• Validate config: haproxy -c -f /etc/haproxy/haproxy.cfg.
• Reload: systemctl reload haproxy.
• Monitor health, tune timeouts/maxconn, and iterate safely.
