How to Use ElasticSearch on Linux Server? Step-by-Step Setup

To use Elasticsearch on a Linux server, install the official package from Elastic’s repository, start the systemd service, and secure access. Configure cluster and network settings in elasticsearch.yml, set an appropriate Java heap size, and test with the REST API. Optionally add Kibana for visualization and schedule snapshots for backups.

Elasticsearch on Linux server gives you a fast, scalable search and analytics engine powered by Lucene. In this guide, I’ll show you how to install, configure, secure, and use Elasticsearch 8.x on Ubuntu/Debian and RHEL-based distributions, then index data and run searches without skipping the production-critical details beginners often miss.

What Is Elasticsearch and Why Use It on Linux?

Prerequisites and Planning

• Server: x86_64 Linux (Ubuntu 20.04+/22.04+, Debian 11/12, RHEL/CentOS/Alma/Rocky 8/9)
• RAM/CPU: Minimum 2 vCPU and 4 GB RAM for trials; 8–16 GB RAM+ recommended for production
• Disk: SSD storage; plan IOPS and capacity for shards, replicas, and retention
• Ports: 9200 (HTTP), 9300 (Transport). Restrict both to trusted IPs/VPC/subnets
• Kernel setting: vm.max_map_count=262144 (required by Elasticsearch memory-mapped files)
• Java: Bundled OpenJDK included in Elasticsearch 8.x packages—no separate JDK needed

Decide whether you’re running a single-node for development (discovery.type: single-node) or a multi-node cluster (separate master/data/ingest roles). Plan for snapshots (S3, GCS, NFS) and monitoring from day one.

Install Elasticsearch on Ubuntu/Debian

These commands add the official Elastic APT repository and install Elasticsearch 8.x.

sudo apt update
sudo apt install -y curl gnupg apt-transport-https
curl -fsSL https://artifacts.elastic.co/GPG-KEY-elasticsearch | sudo gpg --dearmor -o /usr/share/keyrings/elastic-archive-keyring.gpg
echo "deb [signed-by=/usr/share/keyrings/elastic-archive-keyring.gpg] https://artifacts.elastic.co/packages/8.x/apt stable main" | sudo tee /etc/apt/sources.list.d/elastic-8.x.list
sudo apt update
sudo apt install -y elasticsearch

Set the required kernel parameter and persist it:

sudo sysctl -w vm.max_map_count=262144
echo "vm.max_map_count=262144" | sudo tee /etc/sysctl.d/99-elasticsearch.conf

Install Elasticsearch on RHEL/CentOS/AlmaLinux/Rocky

Use DNF/YUM with the Elastic YUM repository:

sudo rpm --import https://artifacts.elastic.co/GPG-KEY-elasticsearch
cat << 'EOF' | sudo tee /etc/yum.repos.d/elasticsearch.repo
[elasticsearch-8.x]
name=Elasticsearch repository for 8.x packages
baseurl=https://artifacts.elastic.co/packages/8.x/yum
gpgcheck=1
gpgkey=https://artifacts.elastic.co/GPG-KEY-elasticsearch
enabled=1
autorefresh=1
type=rpm-md
EOF

sudo dnf install -y elasticsearch

# Kernel parameter
sudo sysctl -w vm.max_map_count=262144
echo "vm.max_map_count=262144" | sudo tee /etc/sysctl.d/99-elasticsearch.conf

First Start, Auto-Generated Passwords, and Verification

In Elasticsearch 8.x, security is on by default. On first start, the installer outputs a temporary “elastic” superuser password and enrollment tokens for Kibana and nodes. Save them securely.

sudo systemctl daemon-reload
sudo systemctl enable --now elasticsearch
sudo systemctl status elasticsearch --no-pager

Verify the node is up. If connecting locally with self-signed certs, use -k to skip certificate verification during tests:

curl -k https://localhost:9200 -u elastic:'YOUR_INITIAL_PASSWORD'

You should see JSON with cluster_name, version, and tagline. Change the default password as soon as you log in.

Essential Configuration for Production

Main settings live in /etc/elasticsearch/elasticsearch.yml. For a secure single-node setup (great for dev or a small production appliance):

# /etc/elasticsearch/elasticsearch.yml
cluster.name: my-es-cluster
node.name: node-1

# Data and logs
path.data: /var/lib/elasticsearch
path.logs: /var/log/elasticsearch

# Bind address (use a private IP or specific interface, not 0.0.0.0 unless firewalled)
network.host: 127.0.0.1
http.port: 9200

# Single-node discovery (remove in multi-node clusters)
discovery.type: single-node

Adjust the Java heap in /etc/elasticsearch/jvm.options (or jvm.options.d/). A good rule is ~50% of RAM, capped at 31g for compressed oops:

# Example for an 8 GB server:
-Xms4g
-Xmx4g

Apply changes after every config edit:

sudo systemctl restart elasticsearch
sudo journalctl -u elasticsearch -f

Network and Security Hardening

Elasticsearch should not be wide-open on the internet. Keep HTTP (9200) limited to trusted IPs or private networks, and secure transport between nodes.

• Firewall: allow SSH and trusted IPs only
• TLS: 8.x enables TLS by default; replace self-signed with your own CA for production
• Users/Roles: use the built-in role-based access control for least privilege
• API Keys: prefer API keys for apps ingesting data
• Backups: configure repository snapshots off-box (S3, GCS, NFS)

# UFW example (Ubuntu)
sudo ufw allow OpenSSH
sudo ufw allow from YOUR_TRUSTED_IP to any port 9200 proto tcp
sudo ufw enable

# firewalld example (RHEL)
sudo firewall-cmd --permanent --add-rich-rule='rule family="ipv4" source address="YOUR_TRUSTED_IP/32" port protocol="tcp" port="9200" accept'
sudo firewall-cmd --reload

To create a least-privilege user for an app that only indexes data to an index pattern, define a role and user:

# Create a role (write to "logs-*")
curl -k -u elastic:STRONG_PASSWORD -H "Content-Type: application/json" \
  -X POST https://localhost:9200/_security/role/log-writer \
  -d '{ "indices": [{ "names": ["logs-*"], "privileges": ["create_index", "write"] }] }'

# Create a user and assign the role
curl -k -u elastic:STRONG_PASSWORD -H "Content-Type: application/json" \
  -X POST https://localhost:9200/_security/user/app-ingestor \
  -d '{ "password": "CHANGEME", "roles": ["log-writer"] }'

Optional: Install Kibana for Dashboards

Kibana provides UI for management, dashboards, and Dev Tools. Install and connect with the enrollment token shown during Elasticsearch setup.

# Ubuntu/Debian
sudo apt install -y kibana
sudo systemctl enable --now kibana

# RHEL family
sudo dnf install -y kibana
sudo systemctl enable --now kibana

Open Kibana (default port 5601) from a trusted IP and complete the guided connection flow.

Index and Search: The Basics

Elasticsearch uses a RESTful JSON API. Below are quick examples to create an index, insert a document, and run a search. Use HTTPS and credentials.

# Create an index
curl -k -u elastic:PASS -X PUT https://localhost:9200/products

# Index a document
curl -k -u elastic:PASS -H "Content-Type: application/json" \
  -X POST https://localhost:9200/products/_doc/1 \
  -d '{ "name": "SSD Hosting", "price": 4.99, "tags": ["hosting","ssd"] }'

# Simple query string search
curl -k -u elastic:PASS -X GET 'https://localhost:9200/products/_search?q=hosting'

# Structured match query
curl -k -u elastic:PASS -H "Content-Type: application/json" \
  -X POST https://localhost:9200/products/_search \
  -d '{ "query": { "match": { "name": "hosting" } } }'

For time-series data (logs, metrics), use index lifecycle management (ILM) to roll over indices automatically and control retention and cost.

Scaling to a Cluster

In multi-node clusters, dedicate roles for stability and performance. A common pattern is 3 master-eligible nodes (for quorum) and N data nodes.

# /etc/elasticsearch/elasticsearch.yml (multi-node example)
cluster.name: prod-es
node.name: node-1
node.roles: ["master","data","ingest"]   # or split roles across nodes
network.host: 10.0.0.11

discovery.seed_hosts: ["10.0.0.11","10.0.0.12","10.0.0.13"]
cluster.initial_master_nodes: ["node-1","node-2","node-3"]

• Shards/Replicas: Default is 1 primary and 1 replica; adjust per index based on size/throughput
• Heap: Avoid swapping; monitor GC. Never exceed ~50% of RAM or 31g heap
• Storage: Prefer NVMe SSDs; isolate logs and data if IO is intense
• Networking: Keep transport traffic on a private network or VPC

Monitoring, Maintenance, and Backups

Use cat and health APIs for quick checks, and integrate with Kibana or external monitors for visibility.

# Health and stats
curl -k -u elastic:PASS https://localhost:9200/_cluster/health
curl -k -u elastic:PASS https://localhost:9200/_cat/nodes?v
curl -k -u elastic:PASS https://localhost:9200/_cat/indices?v

# Snapshot repository (S3 example requires plugin)
sudo /usr/share/elasticsearch/bin/elasticsearch-plugin install repository-s3
sudo systemctl restart elasticsearch

# Register S3 repo
curl -k -u elastic:PASS -H "Content-Type: application/json" \
  -X PUT https://localhost:9200/_snapshot/daily-s3 \
  -d '{ "type": "s3", "settings": { "bucket": "my-es-backups", "region": "us-east-1" } }'

# Take a snapshot
curl -k -u elastic:PASS -X PUT https://localhost:9200/_snapshot/daily-s3/snap-$(date +%F)

Schedule snapshots (cron or orchestrator) and routinely test restores in a staging environment.

Troubleshooting Common Issues

• Service won’t start: check journalctl -u elasticsearch -f. Common causes: file permissions, wrong JVM options, or missing vm.max_map_count
• Connection refused/timeouts: ensure service is running, firewall allows your IP, and network.host is correct
• Red cluster health: missing shards or nodes. Use _cat/shards and logs to identify failures
• High heap/GC pressure: lower shard count, increase heap (within limits), or scale out. Tune refresh intervals and mappings
• Slow queries: add analyzers, use keyword fields for aggregations, and avoid wildcard leading queries

Pros and Cons of Running Elasticsearch Yourself

• Pros: full control, cost-optimized on your hardware, custom security/networking, no vendor lock-in
• Cons: operational complexity (upgrades, shards, scaling, security), on-call burden, careful capacity planning required

When Managed Hosting Helps

If you’d rather focus on your app instead of cluster care, YouStable can provision performance-optimized Linux servers with Elasticsearch pre-installed, secured, and monitored. Our experts handle sizing, backups, and 24×7 support, while you keep API-level control for indexing, search, and dashboards.

Uninstall or Clean Removal (If Needed)

On Ubuntu/Debian:

sudo systemctl stop elasticsearch
sudo apt purge -y elasticsearch
sudo rm -rf /var/lib/elasticsearch /var/log/elasticsearch

On RHEL family:

sudo systemctl stop elasticsearch
sudo dnf remove -y elasticsearch
sudo rm -rf /var/lib/elasticsearch /var/log/elasticsearch

Best Practices Checklist

• Keep Elasticsearch updated to the latest 8.x release
• Separate master and data roles at scale; keep 3 master-eligible nodes
• Set heap to ~50% RAM (max 31g), disable swap, and monitor GC
• Lock down 9200/9300 to trusted networks; use TLS with real certificates
• Use ILM for time-series and snapshots for backups
• Benchmark mappings and queries with real data before go-live
